Our Product Line
Diamond
Cubic Boron Nitride (CBN)
Coated Diamond/CBN

Metal Bond Micron

Provides good surface finishing onto workpiece.
For resin bond, vitrified bond and electroplated bond.
Recommended for polishing glass, PCD, ceramics, tungsten carbide etc.

Economical Type


EA-MW19

Produced from EA-M19 mesh
Angle and irregular shape, Friable, low toughness, uniform Particle Size Distribution, Good Grinding efficiency.
For Lapping, Grinding the hard and fragile material

EA-MW20

Produced from EA-M20 mesh
Angle and irregular shape, low toughness, uniform Particle Size Distribution
high Grinding efficiency and more durable than EA-MW19.
For Lapping, Grinding the hard and fragile material

Medium Type


EA-MW30

Semi-blocky shape, medium-high toughness, uniform Particle Size Distribution, clean
Good combination of high grinding efficiency and high finishing.
For Lapping, Grinding the hard and fragile material

EA-MW40

Produced from EA-M40 mesh
Blocky shape, high toughness, uniform Particle Size Distribution, clean
more durable than EA-MW30 .
For Lapping, Grinding and Fishing the hard and fragile material

Premium Type


EA-MW50

Very blocky shape, higher toughness, Narrow Particle Size Distribution, clean
Very long using life and very high finishing.
For Optical objects, magnet heard, HDD,


EA-MW60

Made from the raw material with higher toughness, particle is with higher Toughness, thus more durable in using.
Very blocky shape. Highest Toughness, Narrow Particle Size Distribution, very clean.
For PCD, Ceramic and the hard and fragile material



Available Sizes:

  • Other sizes are also available according to customer requirement.
  • Provide Particle Size Distribution Report by Laser Size analysis Measurement.

 0-0.2

0-0.25

0-0.5

0-1

0.5-1

0.5-1.5

0-2

1-2

1-3

1.5-3

2-4

2-5

2.5-5

3-6

4-6

4-8

5-10

6-12

8-12

8-16

10-15

10-20

12-22

20-30

22-36

20-40

30-40

36-54

30-60

40-60

54-80
